Manufacture of mobile or stationary filtration systems

CHVALIS PORTABLE AND MOBILE SYSTEMS FOR OIL MAINTENANCE AND CLEANING

They are designed for pumping, filtration and purification of mineral, synthetic and biological oils including hardly flammable HFC liquids based on water / glycol. Power supply as required: 230V, 400V, 24V-DC and ATEX version. Each type is equipped with a 125 µm strainer for suction with the option of "washing" at the outlet, equipped with a filter - optionally 20, 10, 6, 5 and 2 µm or with an "WR" insert for separating water from the oil.

Portable units: (230 V, flow 16-20 l/min, pressure 5-7 bar, filter 6 and 10 µm)

  • type 3A
  • type 3A-NG

Mobile units: (230/400 V, flow 24-50 l/min, pressure 10 bar, filter 20, 10, 5 and 2 µm, insertion WR - oil separation)

  • type 6A
  • type 7A
  • type 9A
  • type 10A

Downloads


We will be glad to send you catalog sheets of filtration systems on request.

Type 6A

Type 7A

Type 9A

Type 7A Rail
